1/3" 10-40mm F/1.4 13VG1040ASIR-SQ

Downloads

Imager Size			1/3
Mount Type			CS
Focal Length			10-40mm
Aperture Range			1.4 – 360
Field of View Angle (Horizontal x Vertical)	1/2	Wide	37.5° x 27.6°
		Tele	9.3° x 7.0°
	1/3	Wide	27.6° x 20.4°
		Tele	7.0° x 5.3°
Focusing Range			0.5m – INF
Operation	Focus		Manual with Lock
	Zoom		Manual with Lock
	Iris		DC Auto Iris
Back Focus (in air)			Wide 12.376 – Tele 18.812mm
Operating Voltage			Open 3.0V Close 0.5V
Weight			89g
Operating Temperature			-20°C – +60°C
